Verified models: 20AM-S0FN00
20AM-006LMN

Types not listed above has to be verified.

Windows 7 updated: 2016-11-28
Windows 10 updated: 2016-12-05
Information:

Lenovos Power Manager software is not implemented and activated for installation in software package.

Ericsson N5321gw Mobile Broadband (3G) component detected will have relevant software installed.
PCs with Sierra WWAN (3G) have never been verfied, so this software is excluded and never tested for instllation.

Intel Bluetooth and Lenovo Hotkey (Function Keys) support software is installed in the software installation step.

WMI information

Run the following command in a console to find the relevant WMI information to use in a Task Sequence:

c:\> wmic csproduct get * /format:list

Windows installation

Drivers installation

Install_Drivers.cmd <some_specific_file_name>_drivers.exe some_specific_file_name>basic_drivers.exe

Software installation

Install_Software.cmd <some_specific_file_name>_software.exe

Installation Drivers Package version 1.2
Alcor Smart Card Reader Driver 1.7.44.0
Broadcom NFC Driver 1.1.0.1398
Intel Chipset Device Software 10.1.1.9
Intel HD Graphics Driver 10.18.14.4414
Intel ME Interface & Serial Over LAN 11.0.5.1189
Intel PRO/1000 LAN Adapter Software 12.13.17.7
Intel Rapid Storage Technology Driver 12.8.10.1005
Intel Smart Connect Technology 1.0.11
Intel USB3.0 Driver 4.0.6.60
Intel Wireless LAN (11abgn, 11bgn, 11ac) 19.1.0
Lenovo Power Management Driver 1.67.12.16
NVIDIA Optimus Display Driver 10.18.13.5474 /10.18.14.4385
Realtek Audio Driver 6.0.1.7746
Realtek Bluetooth 4.0 Software 1.3.769.1
Realtek Card Reader Driver 6.2.9200.21236
Realtek Integrated Camera Driver 6.2.9200.10247
Sunplus Integrated Camera Driver 3.4.7.36
Synaptics Ultranav Driver 18.0.7.109
ThinkPad Finger Print Reader 4.5.263.0
ThinkPad Monitor File 5.07
ThinkPad Wireless LAN (802.11b/g/n) Software 2013.10.1015.2014
Installation Software Package version 1.2
Intel BlueTooth 19.0.1603.0650
Power Manager (software) 6.68.10 (not impl.)
Sierra Wireless EM7355 software 6.21.4431.0106 (not impl.)
Sierra Wireless EM7345 Software 2.21.10890.4498 (not impl.)
Hotkey Feature 8.80.22
Ericsson N5321gw Mobile Broadband 7.2.9.0
Installation Drivers Package version 1.1
Realtek High Definition Audio 6.0.1.7898
Realtek Bluetooth 1.3.865.3
Sunplus/Realtek Integrated Camera 3.4.7.36(Sunplus)
6.2.9200.10252 (Realtek)
Alcor SmartCard Reader 1.7.45.1
Realtek Card Reader (TP T440/T440s) 10.0.10125.21277
Realtek Card Reader (TP X240) 6.3.9600.21275
Intel Smart Connect Technology (TP x240) 1.0.11
Intel Chipset 10.1.1.9
Intel Management Engine Interface 11.0.0.1163
ThinkPad Monitor 6.03
Synaptics ThinkPad UltraNav 19.0.17.85
Lenovo Power Management Driver 1.67.12.18
Intel Collaborative Processor Performance Control 1.0.0.1018
Validity Fingerprint 4.5.507
Intel Rapid Storage Technology 14.5.0.1081
NVIDIA Geforce/Quadro Display 21.21.13.6959
NVIDIA HD Audio 1.3.34.15
Intel HD Graphics (Optimus) 20.19.15.4531
Intel HD Audio 6.16.00.3197
Intel HD Graphics 20.19.15.4531
Ericsson N5321gw / H5321gw Wireless WAN 8.2.5.0
Intel Wireless LAN (11abgn, 11bgn, 11ac) 18.33.3.2
Intel Ethernet 12.15.23.1
Installation Software Package version 1.1
Intel BlueTooth 19.10.1635.483

Miscellaneous

N/A
